Customer Country: Russia

Rock Type: limestone / lime stone

Max. Feed Size: 650 mm

Crushing Capacity: 200 ton per hour

Final product size: 0-5 mm, 5-10 mm, 10-20mm, 20-30mm

Equipments & Plant: Vibrating feeder ZSW-1100×4200 + Jaw Crusher PE 750×1060 + Impact Crusher PF1214 x 2 + Vibrating Screen 3YZS1860 x 2

Vibrating feeder send raw material to PE jaw crusher, the base of the jaw crusher and vibrating feeder are always above the land, our engineer will guide you on how to make foundation.

Two sets of PF1214 impact crushers, they are used to re-crush material to small size.

Two Russian workers are working in installation site, convey machines are at their side waiting for installing.

Vibrating screening machines in the crushing and screening plant are used to separate the material to different types so as to meet customer requirement.

Customer Country: Surinam

Rock Type: quartz stone

Max. Feed Size: 500 mm

Crushing Capacity: 50-100 ton per hour

Final product size: 5 mm, 10 mm, 15mm, 20mm

Equipments & Plant: Vibrating feeder ZSW-960×3800 + Jaw Crusher PE 600×900 + Impact Crusher PF1214 + Vibrating Screen 4YZS1848

Vibrating feeder feed the quartz stone to first crushing machine, jaw crusher, for primary crushing, it also separates the dust from the stone.

After curshed by jaw crusher, materials are conveyed to the impact crusher for second crushing.

Vibrating screen machine which have four layers will separate the final products to different size so as to meet different use. Materials size below 20 mm will be separated and sent individual to the final products piles. The other material will be sent back to impact crusher for recrushing.

Final products will transported by truck to different place. Usually, these materials are widely used in road building, construction, rail way building, airport construction and so on.
